Product Information :

Name :
Automatic Tension Controller PTC-303D, 305D
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. Tension Controller
Brand :
Pora
Model :
Model PTC-303D, 305D
Product Type :
  1. สินค้า, ผลิตภัณฑ์

Product Detail :



PTC-303D, 305D




The digital tension controller is a digital type tension controller which automatically controls the powder brake and powder clutch.

TG voltage control function / strong resistance to surge and noise / sheet cutting function / compensation function



COMPATIBLE SENSORS

PRTL-A,PA Type PRTL-AB Type PRTL-B,C,D,E Type PRTL-TP Type

SPECIFICATIONS
Model PTC-303D

Compatible sensors A, PA, AB, B Type

Input voltage Dual use AC 220V / 380V

Rated capacity 0.3 ~ 65kg·m

Output DC 0 ~ 24V 5A

Weight 7.35kg




This is the panel mounted model of 303D. The control part and the main body are separated so that it can be mounted on a panel.

TG voltage control function / strong resistance to surge and noise / sheet cutting function / compensation function



COMPATIBLE SENSORS

PRTL-A,PA Type PRTL-AB Type PRTL-B,C,D,E Type PRTL-TP Type

SPECIFICATIONS
Model PTC-303D-I

Compatible sensors A, PA, AB, B Type

Input voltage Dual use AC 220V / 380V

Rated capacity 0.3 ~ 65kg·m

Output DC 0 ~ 24V 5A

Weight Panel : 0.5Kg, Main body box : 5.5kg




This is a model developed by simplifying the operating functions of 303D.



COMPATIBLE SENSORS

PRTL-A,PA Type PRTL-AB Type PRTL-B,C,D,E Type PRTL-TP Type

SPECIFICATIONS
Model PTC-305D

Compatible sensors A, PA, AB, B Type

Input voltage Dual use AC 220V / 380V

Rated capacity 0.3 ~ 65kg·m

Output DC 0 ~ 24V 5A

Weight 7kg




This is the panel mounted model of 305D. The control part and the main body are separated so that it can be mounted on a panel.



COMPATIBLE SENSORS

PRTL-A,PA Type PRTL-AB Type PRTL-B,C,D,E Type PRTL-TP Type

SPECIFICATIONS
Model PTC-305D-I

Compatible sensors A, PA, AB, B Type

Input voltage Dual use AC 220V / 380V

Rated capacity 0.3 ~ 65kg·m

Output DC 0 ~ 24V 5A

Weight Panel : 0.5Kg, Main body box : 5.5kg
