E-Catalog > 993 A-Ryung Coolant Pump > Coolant Pump ACP-HMFC

This type is multistage and used high quantity flowing of oil for the large machine with high precise and efficiency. It is proper to make working surface slick flowing down and washing the chips by cooling fluid..

As the motor is separated from pump part, the high temperature of motor does not transfer directly to pump, so oil temperature keeps constantly.

The divider should be installed between inlet and outlet to protect reduction of suction power by mixing dust, and keep 40mm distance between pump casing and tank bottom.

When installed added pipe at inlet, the bottom casing should be submerged over 1 stage to avoid not sucking at first operation.

The special mechanical seal improves pump life.

Horizontal typed self suction should completely fill with oil fluid into the outlet at first operation.
