E-Catalog > Guide & Cylinder > Single Type Motor Guide Roller PR-MES, MED Type

PAGE VIEW : 13,872

Product Information :

Name :
Single Type Motor Guide Roller PR-MES, MED Type
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. Guide & Cylinder
Brand :
Pora
Model :
Model PR-MES, MED Type
Product Type :
  1. สินค้า, ผลิตภัณฑ์

Product Detail :



PR-MES, MED Type




This product directs the material to the exact position before it reaches the printing point or cutting point using a motor (the end pivot type).



SPECIFICATIONS
Model PR-MES Type

Motor capacity 15 40

Gear ratio 6:1 10:1 18:1 6:1 10:1 18:1

Allowable
thrust(kgf)		 20 35 75 60 95 200

Operation
velocity(mpm)		 600 400 100 600 400 100

Allowable weight 20kgf 50kgf

Maximum
control angle		 ±5.2°

Input DC ±24V

Weight 15kg (Excluding roller)




This product directs the material to the exact position before it reaches the printing point or cutting point using a motor (the end pivot type).



SPECIFICATIONS
Model PR-MED Type

Motor capacity 15 40

Gear ratio 6:1 10:1 18:1 6:1 10:1 18:1

Allowable
thrust(kgf)		 20 35 75 60 95 200

Operation
velocity(mpm)		 600 400 100 600 400 100

Allowable weight 20kgf 50kgf

Maximum
control angle		 ±5.2°

Input DC ±24V

Weight 19kg (Excluding roller)
