PT-LM106D is a Load Cell Type Digital Tension Meter with an imbedded high functional converter Being compact, it is easy to utilize space and the device can be simply set.
Auto zero function / Hunting prevention adjustment function / Alarm indication function
|
|
|
| |
| |
| COMPATIBLE SENSORS |
 |
 |
 |
 |
|
| PRTL-A,PA Type |
PRTL-AB Type |
PRTL-B,C,D,E Type |
PRTL-TP Type |
|
|
| |
| SPECIFICATIONS |
| Model |
PT-LM106D |
| |
| Compatible Sensor |
A, PA, AB, B, C, D, E, TP(For high load) Type |
| |
| Power Input |
AC 110V/220V ±10%, 50/60Hz Power consumption 10VA |
| |
| Output |
DC 0 ~ 10V / 4 ~ 20mA |
| |
| Display |
Digital display of 5 digits by 7 segment LED |
| |
| LED Display |
Identification display of tension value output in %,
power display and zero display by 8 LEDs |
| |
Voltage Applied to
Load Cell |
DC 5V ±5%, 100㎃ (4 load cells of 350Ω can be connected.) |
| |
Maximum Value
Display |
-19999 ~ +99999 |
| |
| A/D Converter |
High precision AD is used (24bit-Sigma-Delta). 500 times/sec |
| |
| D/A Converter |
High precision DA is used, 500 times/sec |
| |
| Nonlinearity |
0.01% F.S. |
| |
Maximum Load Cell
Input Voltage |
Max. ±20mA Min. 0mA
※Standard input : Rated output 3mV/V load cell (recommend) |
| |
Zero Point
Adjustment Scope |
0mA ~ ±20mA |
| |
| Input Sensitivity |
0.5μV/D or higher |
| |
| Accuracy |
Zero point: ±0.1μV/℃ RTI max. |
| |
| Input Noise |
±0.3μVpp or lower |
| |
| Input Impedance |
10㏁ or higher |
| |
| AD Internal Resolution |
1/200,000 |
| |
| AD External Resolution |
1/30,000 |
| |
| Weight |
375g |
|
|
|
|
