Product Information :

Name :
PRB-W3 (Indirect Water Cooled Type)
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. Powder Brake
Brand :
Pora
Model :
Model PRB-W3
Product Type :
  1. สินค้า, ผลิตภัณฑ์

Product Detail :





PRB-W3 (Indirect Water Cooled Type)




You can use the Powder Brake/Clutch that has exellent magnetic force control in wide range of industrial machines sinse it is simple to attach and 100% compatible with international and food machines.




Model Torque
(Nm)
Voltage
(DC V)
Current
(A)
Power
(W)
Powder
Quantity
(g)
Rev
Count
(rpm)
Rate of Slip
Production(W)
Bearing
Specification
Weight
(kg)
PRB-2.5W₃ 25 24 2.7 64.8 50 800 700 #6005/#6205 10

PRB-5W₃ 50 3.5 84 80 800 1200 #6206 16

PRB-10W₃ 100 2.9 69.6 120 500 2800 #6207 34

PRB-20W₃ 200 3.7 88.8 200 500 3900 #6308 48

PRB-40W₃ 400 4.3 103.2 450 500 5200 #6210/#6310 109

PRB-65W₃ 650 4.8 115.2 1000 500 7000 #6313/#6314 133
